32Channel 8MP H.265+ HD Pentabrid HD-TVI/CVI/AHD IP & Analog DVR

  • Model: DSC-AR526-32
  • Shipping Weight: 20lbs
  • 10 Units in Stock
  • Manufactured by: HIKVISION

$799.95

Add to Cart:

(4K)8MP 32 Channel HD Security DVR supports HD-TVI Security Cameras up to 8MP/4K and CVI/AHD Cameras up to 1080P

(Support TVI, AHD,CVI, Analog, and IP cameras)

* works with HD-TVI (turbo HD)/HD-AHD/HD-CVI/ IP Hikvision / analog cameras***

***Not work for HD-SDI Camera***

** Iphone apps : IVMS-4500 or Guarding Vision
** Android apps: IVMS-4500 or Guarding Vision

*This product is unbranded for OEM. No Hikvision logo or model number is on the product.



  • 1.5U case with 4 HDD interface
  • 32 Channel Video Recorder
  • Support HD-TVI (up to 8MP) / AHD/ ANALOG / CVI / IP input (5 in 1)
  • Support Live View, Storage, Playback up to 32 HD-TVI/Analog Cameras + 8 IP Cameras up to 8MP
  • Up to 40CH  4K(8MP) IPC input
  • Up to 4K (3840*2160) HDMI Video Output
  • HDMI 1/VGA output @1920*1080, HDMI 2 output@ 4K,  CVBS output
  • 4 SATA up to 8TB each HDD
  • 2 USB 2.0/ 1 USB 3.0
  • RAID 0, 1, 5, 6, 10
Video/Audio Input
Video Compression H.265+/H.265/H.264 Zip+/H.264
Analog and HD-TVI Video Input 32CH / BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input 8MP, 5 MP, 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
AHD Input 5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI Input 1080p25, 1080p30, 720p25, 720p30
CVBS Input PAL/NTSC
IP Input 8-ch (up to 40-ch); Up to 8 MP resolution; Supports H.265+/H.265/H.264+/H.264 IP cameras
Audio Compression G.711u
Audio Input 4-ch, RCA (2.0 Vp-p, 1kΩ)
Video/Audio Output
CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
HDMI/ VGA Output HDMI1/VGA: 1 -ch , 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60 Hz

HDMI2: 1-ch, 4K(3840 × 2160)/30Hz, 2K(2560 × 1440)/60Hz, 1920× 1080/60Hz, 1280 × 1024/60Hz,1280 × 720/60Hz, 1024 × 768/60 Hz
Encoding Resolution 8 MP/ 5 MP/4 MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame Rate Main stream:  8MP@8fps/ 5MP@12fps/4 MP@15fps/3 MP@18fps,1080p/720p/WD1/4CIF/VGA/CIF@25fps(P)/30fps(N)
Sub-stream: WD1/4CIF/CIF@25fps (P)/30f ps ( N)
Video Bit Rate 32Kbps-10Mbps
Audio Output 1-CH, RCA (Linear, 1 kΩ)
Audio Bit Rate 64 Kbps
Dual-Stream Support
Stream Type Video, Video & Audio
Synchronous Playback 16CH
Network
Remote Connections 128
Network Protocols TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS
Hard Disk
SATA 4 SATA Interfaces for 4 HDDs; 1 eSATA interface
Capacity Up to 8TB capacity for each disk
External Interface
Network Interface 2, RJ45 10M/100M/1000Mself-adaptive Ethernet interface
Serial Interface RS-232, RS-485 (full duplex), Keyboard
USB Port Front panel 2 x USB 2.0 / 1x USB 3.0
Alarm In/Out 16/4
General
Power Supply AC100 to 240V
Consumption ≤65W
Working Temperature -10°C ~ 55°C(14°F-131°F)
Working Humidity 10%~90%
Chassis 1.5U Chassis
Dimensions (WxDxH) 445 x 390 x 70mm (17.5x15.3x2.7inch)
Weight ≤7Kg (15.4lb)
